KDE DIRECT ALIGN TREX 700 ELECTRIC SERIES
METAL BOTTOM PLATE ULTRALIGHT

The new KDE Direct TREX 700 Electric Series Metal Bottom Plate Ultralight upgrade is now available; providing an FEA-optimized, Aluminum 6061-T6 crossbar construction that prevents flex during high-torque maneuvers of both the helicopter lower frame section and the connected tail boom braces. Compatible with all TREX 700 Electric Series helicopters (DFC and V1/V2), the new upgrade provides unprecedented strength in an ultralight design – weighing only 62 grams (~17 grams less than the stock DFC edition).

In addition, for the ultimate hold of the tail boom braces, don’t pass on the KDE Direct TREX 700/800 Series Tail Boom Mount Adapters. The adapters can be used on both sides of the tail boom braces (sold in pairs) for improved durability and strength.

METAL BOTTOM PLATE ULTRALIGHT
FOR ALIGN TREX 700 ELECTRIC SERIES HELICOPTERS

Item Number: AT700E-MBPUL

Price: $41.95
Material: Aluminum 6061-T6
Models: all ALIGN TREX 700E (V1/V2/DFC) series.

Recommended Accessories:
KDE DIRECT 700 SERIES PERFORMANCE BOOM SUPPORT ASSEMBLY

Note: the Metal Bottom Plate Ultralight design provides an FEA-optimized, Aluminum 6061-T6 crossbar construction that prevents flex during high-torque maneuvers of both the helicopter lower frame section and the connected tail boom braces. Compatible with all TREX 700 Electric Series helicopters (DFC and V1/V2), the new upgrade provides unprecedented strength in an ultralight design – weighing only 62 grams (~17 grams less than the stock DFC edition).

Includes:
- One (1) TREX 700E Series Aluminum Metal Bottom Plate Ultralight

- Twelve (12) M3 x 0.5 x 8 mm Socket Head Cap Screws (Class 12.9 BP Alloy Steel)
- Two (2) M4 x 0.7 x 16 mm Socket Head Cap Screws (Class 12.9 BP Alloy Steel)

Finish:
Clear anodize, mirror-polish CNC gloss

Weight:
62 g (design is FEA optimized for maximum strength and minimum weight)

Line Break - Medium Yellow

TAIL BOOM MOUNT ADAPTERS
FOR ALIGN TREX 700/800 SERIES HELICOPTERS

Item Number: AT700-TBMA
Installation Diagram: CLICK HERE

Price: $12.95
Material: Stainless Steel 17-4PH
Models: all ALIGN TREX 700E (V1/V2/DFC), 700N (V1/V2/DFC), and 800 (DFC/Conversion) series. Also compatible with other 700/800-class helicopters, such as the OUTRAGE Velocity 90 and SYNERGY E6/E7.

Recommended Accessories:
KDE DIRECT 700 SERIES PERFORMANCE BOOM SUPPORT ASSEMBLY

Note: the TREX 700/800 series Tail Boom Mount Adapters are the ideal solution for preventing unwanted loosening and failure of the tail boom braces caused by the high-vibration nature of the helicopter. Using a high-strength, SS 17-4 PH construction and CNC-precision machining, the chance of failure is greatly reduced and provides a simple, hassle-free method for tail boom support assembly installation and removal. Can be used on both sides of the tail boom braces (sold in pairs) for improved durability and strength.

Includes:
- Two (2) TREX 700/800 Series Stainless Steel Tail Boom Mount Adapters

- Two (2) M4 Flat Washers (Stainless Steel)
- Two (2) M4 x 0.7 Nylon-Insert Locknuts (Zinc-Plated Class 8 Alloy Steel)

Weight:
Tail Boom Mount Adapters: 2 g ea. (design is FEA optimized for maximum strength)

Line Break - Medium Green

E-FLITE BLADE 130X SERIES UPGRADES

The E-Flite Blade 130X is a great indoor helicopter and we’re proud to continue supporting this helicopter line, with a sneak-peak of upcoming releases from KDE Direct. New KDE Direct E-Flite Blade 130X Series XF Main Rotor Blades are coming soon, and the technology in these blades are sure to change your view of flight performance. Engineered with an aerospace-proven airfoil for unreal stability, these blades are sure to excite all pilots worldwide. No need for ugly “bullet” blades to compensate for incorrect airfoils and manufacturing limitations, these are blades that use technology to drive the performance. In addition, the KDE Direct E-Flite Blade 130X Series Tail Servo Boom Mount and Tail Pushrod Support upgrades are coming soon – stay tuned!

Line Break - Medium Green

LATEST VIDEOS FROM CUSTOMERS

New videos have been sent to us from customers enjoying the KDE Direct upgrades on their personal helicopters. Special thanks to Chris and Roger for their latest videos, all running KDE Direct XF Brushless Motors and a host of upgrades on various setups. Motors have been so popular, we are almost sold-out across the board, but don’t fret – a whole new production run is in the works and will be arriving early 2013; with a host of improvements and new technology to further establish the motors as the industry-leaders in performance.

KDE Direct powered Goblin 700 (700XF-495) – John Thompson @ Orlando Heli Blowout 2012

YouTube Preview Image

John Thompson of Team HeliDirect flies a Goblin 700 powered by KDE Direct’s 700XF-495 brushless motor! (It’s also sporting the new KDE Direct canopy!)

Line Break - Medium Yellow

T-REX 550DFC / KDE XF MOTOR

YouTube Preview Image

Line Break - Medium Yellow

T-REX 450DFC / KDE XF MOTOR/ BEASTX

YouTube Preview Image
