Heli-Max Axe 100 SS

This is not the same Axe 100 CP that pilots already know. It’s the Axe 100 SS (Super Sport Brushless), the one that everyone will be flying in the future. It retains the flybarless collective-pitch head design and TAGS three-axis gyro of the CP, but adds a brushless power system and an extended tail boom for achieving 3D mastery. Available in an RTF version for the maximum ease, and another that offers the full potential and flexibility of Tx-R (Transmitter-Ready) flying!

● Brushless-powered for handling the most demanding stunts.
● Beefed-up airframe molded to accommodate the demands of brushless power.
● Individual controller and servos maximize performance and simplify replacement.
● Extended tail boom for improved tail authority.
● Dependable, responsive motor-driven tail rotor
● Ideal for indoor and outdoor flying.

Enjoy all-in-one convenience — and start flying in minutes!

The RTF includes a TTX610
6-channel 2.4GHz transmitter with:

● Secure Link Technology
● 10-model memory
● 5-point pitch curve
● Exponential
● Digital trims
● Adjustable gyro sensitivity

Other features include:

● The assembled Axe 100 SS
● TAGS three-axis gyro
● Installed receiver & servos, 14,750kV outrunner brushless motor & 10A brushless controller
● 3.7V 400mAh LiPo battery
● Variable-rate, balancing AC LiPo charger
● Spare main blades, tail rotor, linkages, and screwdriver

HMXE0824 – RTF
Rotor Diameter: 9.5 in (242 mm)
Weight (w/o battery): 1.7 oz (48 g)
Length: 10.4 in (264 mm)
Requires: (8) “AA” alkaline batteries

Recommended Options:
GPMM3105 JST to Banana Plug Charge Adapter
HMXE2123 Heli-Max 1S to JST Male Adapter

Fly the Axe 100 SS — and other Tx-R aircraft — with your transmitter!

There’s a lot to like about the Tx-R concept. Assembly is done, so there’s no work or waiting. All onboard gear is factory-matched and installed to guarantee top performance. But the single biggest thing to like about Tx-R is the fact that you can use your favorite transmitter to fly all the Tx-R aircraft you want.

Buy a new transmitter? There’s no need. If your 6-channel is compatible with SLT, you’re good to go as is.

And if it’s not, there’s the AnyLink. It’s compatible with virtually any transmitter, regardless of brand, band and modulation. Installing it is as easy as plugging it into your transmitter’s trainer or DSC port. And once you do, your transmitter will broadcast a 2.4GHz signal compatible with the SLT receiver installed in all Tx-R models. And today, “all” not only includes Heli-Max helis, but fixed-wing choices from Flyzone and Great Planes that range from micro bipes to brushless jets.

See Tx-Ready.com for details on transmitter compatibility and adapter requirements.

The Tx-R includes:

● The assembled Axe 100 SS
● TAGS three-axis gyro
● Installed receiver & servos, 14,750kV outrunner brushless motor & 10A brushless controller
● 3.7V 400mAh LiPo battery
● Variable-rate, balancing AC LiPo charger
● Spare main blades, tail rotor, linkages, and screwdriver

HMXE0825 – Tx-R
Rotor Diameter: 9.5 in (242 mm)
Weight (w/o battery): 1.7 oz (48 g)
Length: 10.4 in (264 mm)
Requires: AnyLink & compatible 6-channel heli radio or
6-channel helicopter radio with SLT

Recommended Products:
TACJ2650 Tactic TTX650 6-Channel 2.4GHz SLT Computer Radio System or
FUTK6000 Futaba 6J 6-channel 2.4GHz S-FHSS Computer Radio System and
TACJ2000 Tactic AnyLink 2.4GHz Radio Adapter

Recommended Options:
GPMM3105 JST to Banana Plug Charge Adapter
HMXE2123 Heli-Max 1S to JST Male Adapter

Ask your hobby dealer for additional recommendations.

Nick Maxwell with the new Axe 100 SS (brushless version)

YouTube Preview Image

Source: Heli-Max and Nick Maxwell
