JR recently released a new gasser for all your aerial photog and heavy lift apps!

main

It has been 6 years passed since the multi-discipline GSR260 Helicopter was released.  Now, it’s reborn as GSR260Z with the new ASG 90 rotor head.  It is planned to be released in November 2009.

Specification:

  • Overall length: 1,623 mm
  • Overall height: 704 mm
  • Overall width: 380 mm
  • Gross weight: 7,800 g~ (including main rotor blades JRC800)
  • Main rotor diameter: 1,765 mm (w/JRC800)
  • Tail rotor diameter: 288 mm
  • Gear ratio: 8 : 1 : 5.18
  • Swash: 120 CCPM (MPM is also available as an option)

Key Features:

  • All metal made ASG90 rotor head
  • Redesigned FRP boy
  • Stylish yellow stream-line body
  • Spiral gears increase durability, gear ratio is same as before
  • Brace clamp is made from plastic to prevent if from generating noise
  • Fuel tank cap allows for easy re-fuelling
  • Carbon tail rotor blades 105 mm in length
  • 800 mm Main rotor blades are included
  • Redesigned Fan cover and larger diameter Cooling fan provide more efficient cooling
  • HG Clutch set supplied as standard
  • 12 mm Main shaft
  • Payload 4,000 ~ 5,000 g

head

frame2

Here’s a video showing the aerial photography view from under the new model:

YouTube Preview Image

More information can be found at JR’s website!
